Inca Automatic planer-thicknesser (343.190), reconditioned, stock no. 343.190.010
Inca Automatic planer-thicknesser (343.190 · US 510/550/560/570) · stock no. 343.190.010
Heavy item delivery in France: €50.00.
Before you order, check the rating plate against your workshop supply: 230 V single phase or 400 V three phase.
- Sent from Saint-Rémy, France
Fits / Category
Delivery and returns
Heavy item delivery in France: €50.00.
Specifications
Some machines are worth keeping. The Automatic is one of them.
This Automatic (343.190 · US 510/550/560/570) had been used for only a handful of jobs before it reached us. Like every Automatic it surfaces on a 1,040 mm table and thicknesses up to 260 mm wide and 160 mm deep.
Injecta, the Swiss firm behind Inca, began die-casting in 1921 under a licence from Doehler of New York.
Keep the plastic feed pinions greased with Molykote DX: they are the model's known weak point.
In the box: the machine and its user manual. It is the bench model, without a stand.
Electrics: the Automatic was made for 220 V single phase (1.5 hp) or 380 V three phase (2 hp), with a no-volt release switch; we tell you which this is. Before you order, check the rating plate against your workshop supply: 230 V single phase or 400 V three phase.
| Stock no. | 343.190.010 |
| Model | Inca Automatic (343.190 · US 510/550/560/570) |
| Planer table | 1,040 mm |
| Thicknesser table | 400 mm |
| Cutting width | 260 mm |
| Thicknessing depth | 160 mm |
| Max. cut | 3 mm per pass |
| Cutter block | 60 mm, 6,000 rpm |
| Feed | 3.5 or 5 m/min |
| Fence | tilts to 45°, 180 mm travel |
Built to last decades. Looked after to last a few more.
